Buy a digital inclinometer with a single axis, USB1.1 output signal, optional measuring range ±15°/±30°, and angle measuring solution 0.001°. It is a high-accuracy slope inclinometer, used in building construction, automobile four-wheel testing, industrial platform, machinery installation, and medical instruments.
Multi-functional high-precision digital inclinometer supports data storage.
- Data store function, absolute/relative measurement can switch.
- Both sides and bottom can be measured, double benchmark strong magnet installation.
- Auto-angle interleaved compensation function and auto temperature drifts compensation.
- Built-in rechargeable industry batteries and night vision fours colors screen.
- Filter frequency optional.
Digital inclinometer can complete 360-degree measurements in 4 directions.
- When the inclinometer is turned upside down, the angle readings displayed on the LCD will automatically flip upwards for easy reading.
- Precise stainless steel measuring structure.
- It can be re-calibrated without any special tools and equipment.
- Multi-purpose measuring tool, three-in-one protractor, inclinometer and spirit level.
- A 3-volt battery lasts for 3000 hours.
Applications
sisco digital inclinometer is a measuring tool for measuring small angles, which is widely used in railway systems, water conservancy systems, industrial automation, automobile industry, machinery industry, construction industry and other industries that need to measure and control angles.
| Model | DMI810-15 | DMI810-30 |
| Angle Measuring Range | ±15° | ±30° |
| Mm Measuring Range | 267mm | 577mm |
| Millimeter Measuring Accuracy | 0.1 mm (RMS) | 0.2 mm (RMS) |
| The Highest Measuring Accuracy | ＜0.005 (Full measuring range) | ＜0.001 (Full measuring range) |
| Measuring Axis | Single axis | |
| Angle Measuring Solution | 0.001° | |
| Three Measuring Mode Selectable | Radian, Angle, mm/meter can be set | |
| Absolute Accuracy | 0.05°/rms | |
| Millimeter Measuring LCD | 0.02 mm | |
| LCD | 64-color true color luminous display | |
| LCD Visible Area Size | L57.6mm*W43.2mm | |
| Working Temperature | -10℃-70℃ | |
| Working Humidity | 85% RH | |
| Power Supply | 3.7V Charging Lithium Battery | |
| Ideal Charging Time | 5h | |
| Battery Sustainable Charging Times | 11h | |
| Output Signal | USB1.1 (Virtual Serial Device) | |
| Equipped with PC Software | VC Software | |
| Connect Plug in | Standard 5 Pin USB Connector | |
| Shock Resistance | 10g @11ms, three-axis (Half sine wave) | |
| Shock Impact | 10g RMS, 10-100Hz | |
| Weight | 300g | |
| Waterproof Grade | IP54 | |
| Material | Aluminum Anodizing | |
| Size | L107mm*W75mm*H27.1mm | |
| Certificate | CE, FCC, ROHS | |
Dimension (Unit: mm)
Measuring Direction
Q1: What is a digital inclinometer?
A2: A digital inclinometer is a measuring tool for measuring small angles, which can measure the inclination of the horizontal position, the mutual parallelism and perpendicularity of the two parts, the straightness of the machine tool and the instrument guide rail, the flatness of the worktable, and the flatness of the flat plate, etc.
Q2: How does a digital inclinometer work?
A2: When the shaft in the base of the digital display angle meter rotates in one direction, the count increases, and when the rotation direction changes, the count decreases. The count is related to the initial position of the digital inclinometer. When the inclinometer is initialized, its count value is set to 0. By calculating the angle of rotation, the position and velocity can be easily measured.
Q3: What is an inclinometer used for?
A3: Inclinometers are mainly used in high-precision laser instrument leveling, engineering machinery equipment leveling, long-distance ranging instruments, high-altitude platform safety protection, pitch angle measurement of directional satellite communication antennas, ship navigation attitude measurement, shield pipe jacking applications, dams Detection, tilt monitoring of geological equipment, measurement of initial firing angle of artillery barrels, detection of radar vehicle platform, attitude detection of satellite communication vehicles, etc.
Tips for using a digital inclinometer
- Keep it clean when in use, and wipe the instrument regularly.
- The working temperature should be kept at 0℃~4o℃.
- Sensitivity will decrease due to usage conditions or time, so it should be calibrated regularly to maintain basic accuracy.
- The relative humidity of the environment should be ≤80%.
- After use, it should be placed in a dry environment.
