The nitrogen Oxides (NOX) detector features a lightweight, ergonomic design with a high-contrast LCD, intuitive controls, and real-time data logging. Whether you're conducting low-level ambient air monitoring or high-concentration NOX gas leak detection, this device delivers reliable and accurate measurements every time.
NOX gas detector with dual unit measurement
- SISCO portable nitrogen oxides gas detector provides a clear, real-time readout of gas type, unit, concentration, and local time, enhancing usability in various environments.
- Easily switch between English and Chinese for versatile operation, making it suitable for different regions and users.
- Quickly shift between PPM and mg/m³ for gas concentration measurements, offering flexibility in various applications.
- Includes a 10-grade adjustable suction system, allowing for precise sampling in different conditions.
Customizable alarm system
- High-strength engineering plastic housing offers anti-slip, waterproof, dustproof, and explosion-proof protection, ideal for tough working conditions.
- Certified explosion-proof design ensures safety in hazardous environments where flammable gases are present.
- The handheld nitrogen oxides gas detector is equipped with self-calibration and zero calibration features for highly accurate and reliable gas detection.
- Two-stage sound and light alarm with adjustable alarm points, providing timely warnings in dangerous situations.
Details
Applications
Nitrogen Oxides (NOX) gas detectors are widely used in industrial emissions monitoring, vehicle exhaust testing, ambient air quality control, and laboratory gas analysis to detect harmful NO and NOâ‚‚ gases for safety and regulatory compliance.
Air Quality Testing
Laboratory Analysis
Vehicle Exhaust Emissions
Industrial Emissions
Â
| Model | GD200-NOX |
| Sampling Method | Pumping suction, flow rate can be up to 750ml/min |
| Detection Principle | Electrochemistry |
| Gas | Nitrogen Oxides NOX |
| Range (Optional) * | 0-1ppm, 0-5ppm, 0-10ppm, 0-20ppm, 0-50ppm, 0-100ppm, 0-250ppm, 0-500ppm, 0-1000ppm |
| Resolution | 0.001ppm (0-1/5/10ppm), 0.01ppm (0-20/50ppm), 0.1ppm (0-100/250ppm), 1ppm (0-500/1000ppm) |
| Accuracy | ≤±3% F.S. |
| Response Time | ≤10s |
| Repeatability | ≤±1% |
| Recovery Time | ≤10s |
| Linearity Error | ≤±1% |
| Zero Shift | ≤±1% (F.S./year) |
| Data Logging (Optional Function) | High speed data transmission by USB, available for data downloading and printing (The built-in IC card has about 2G memory, which can record 100,000 sets of data.) |
| Alarms | Sound, light and vibration |
| Display | LCD dot matrix display |
| Language | Chinese/English |
| Battery | 3.7V rechargeable lithium battery, 3.7 Watt (Charger included: Input AC 100-240V 50/60Hz with optional USA, Europe or UK plug) |
| Operating Time | 100h (Pump off) |
| Communication | Mini USB interface supports standard MODBUS communication protocol |
| Explosion-proof Grade | â…¡ 2G Ex ia â…¡ CT4 Ga |
| Case Material | ABS+PC |
| Protection Grade | IP66 |
| Certification | CE, ATEX (Standard: EN IEC 60079-0:2018, EN 60079-1:2014) |
| Operating Temperature | -20℃~50℃ |
| Operating Humidity | 0~95%RH (non-condensing) |
| Operating Pressure | 0.8~1.2bar |
| Dimension | 205*75*32mm |
| Weight | 300g |
| Warranty | 12 months |
| Extension Probe | About 480mm (Total Length), About 300mm (Probe Head) |
| Accessories (Optional) | Calibration kit - gas pressure regulator (calibration gas cylinder NOT included)
|
Gas Detector Catalog & User Manual
SISCO Gas Detector Catalogue- SISCO GD200 Portable Gas Detector User Manual
- SISCO GD300 Online Fixed Gas Detector User Manual
- SISCO GD400 Explosion Proof Portable Gas Detector User Manual
- SISCO GD500 Handheld Multi Gas Detector User Manual
- SISCO GD600 Multi Gas Analyzers User Manual
- SISCO Gas Detector Communication Protocol V1.0
- SISCO Single Stage Pressure Regulator User Manual
- SISCO Gas Detector Data Downloading Operation Instruction
Gas Detector Software
Q1:Â What is a gas detector?
A1:Â A gas detector is an instrument for gas leakage concentration detection, including a portable gas detector, handheld gas detector, fixed gas detector, online gas detector, etc.
Q2:Â What does a gas detector detect?
A2:Â Combustible gases: Natural gas (methane), liquefied gas, coal gas (hydrogen), acetylene, pentane, alkynes, acetone, toluene, alcohols, hydrocarbons, light oil, etc.
Toxic gases: Carbon monoxide, hydrogen sulfide, ammonia, chlorine, oxygen, phosphine, sulfur dioxide, hydrogen chloride, chlorine dioxide and other toxic and harmful gases.
Q3:Â What is ppm of gas detector?
A3:Â Parts per million or "ppm" is often used as a fractional measure of concentration. For example, a methane (molecular) concentration of 2% means that 2 out of every 100 air molecules are methane. Likewise, a methane concentration of 2 ppm means that 2 out of every 1 million air molecules are methane.
Tips: What gases does the NOx gas detector measure?
A portable NOx gas detector is specifically designed to measure nitrogen oxides, primarily nitrogen monoxide (NO) and nitrogen dioxide (NOâ‚‚). These two gases are the major constituents of NOx emissions, commonly produced by combustion processes such as those in vehicles, industrial facilities, and power plants. Depending on the detector model, the device may include separate sensors for NO and NOâ‚‚, allowing for individual readings as well as a calculated total NOx value. Some advanced detectors may also offer additional gas detection capabilities or data logging features for environmental monitoring and compliance testing. Always refer to the product specifications to confirm the exact gases measured and sensor ranges.
